Page D-7
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
63 612418 GEAR ADJUSTER (DRIVER SIDE)......................................................... 1
64 612417 GEAR ADJUSTER (PASSENGER SIDE) ................................................. 1
65
66
67 17083G2 HEX HEAD BOLT, 5/16" - 24 X 1" LG.............................................................. 8
68 15126G1 LOCK NUT, 5/16" - 24 ..................................................................................... 8
69 15485G1 FLAT WASHER, 1/4" ....................................................................................... 2
70
71 19186G1 BRAKE DRUM ASSEMBLY (INCLUDES ITEMS 72 & 73).............................. 2
72 18500G2 BRAKE DRUM .......................................................................................... 1
73 19862G1 LUG BOLT, 1/2" - 20 X 1 3/16" LG............................................................ 4
74
75
76 15487G1 FLAT WASHER, 1 3/8" O.D............................................................................. 2
77 612928 CASTELLATED NUT, 5/8" - 18........................................................................ 2
78 10387G1 COTTER PIN, 1/8" X 1 1/2" LG....................................................................... 2
79
80 652248 BRAKE CABLE BRACKET (PASSENGER SIDE)........................................... 1
81 652249 BRAKE CABLE BRACKET (DRIVER SIDE) ................................................... 1
82
83 70690G02 BRAKE PEDAL ASSEMBLY (WITH BRAKE LIGHTS)
(INCLUDES ITEMS 84 - 110).......................................................................... 1
84 652791G03 BRAKE PEDAL ......................................................................................... 1
85 652253G03 PARK BRAKE PEDAL............................................................................... 1
86
87 70257G01 SERVICE BRAKE PAD............................................................................. 1
88 70256G01 PARK BRAKE PAD ................................................................................... 1
89 16409G1 OVAL RIVET, 3/16" X 7/16" LG................................................................. 9
90
91 652820 SERVICE BRAKE PEDAL PLATE ............................................................ 1
92 70682G01 PIVOT PIN ................................................................................................ 1
93 70681G01 TORSION SPRING................................................................................... 2
BRAKES
