When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page D-8
Service Parts Manual
94 658825 PUSHNUT, 5/16" ...................................................................................... 2
95 00737G8 PHILLIPS FLAT HEAD SCREW, #10 - 24 X 1" LG................................... 4
96 00739G1 RUBBER NUT, #10 - 24 ........................................................................... 2
97 652355 BRAKE PEDAL SPACER ......................................................................... 2
98 27137G01 CONICAL SPRING................................................................................... 2
99 14390G10 LOCK NUT, #10 - 24................................................................................. 2
100 10606G8 MICRO SWITCH ...................................................................................... 1
101 00645G2 PHILLIPS PAN HEAD SCREW, #6 - 32 X 1 1/4" LG................................ 2
102 00559G5 FLAT WASHER, #10 ................................................................................ 2
103 00559G3 FLAT WASHER, #6 .................................................................................. 4
104 00565G3 LOCK WASHER, #6 ................................................................................. 2
105 00525G5 HEX NUT, #6 - 32..................................................................................... 2
106 13514G1 PHILLIPS PAN HEAD SCREW WITH LOCK WASHER, #6..................... 2
107 00642G8 FLAT WASHER, 5/16" .............................................................................. 2
108 14628G1 FASTON TAB............................................................................................ 2
109 24605G1 WIRE HARNESS, BRAKE LIGHT............................................................ 1
110 17618G1 NYLON CLAMP........................................................................................ 2
111 612558 COMPENSATOR ASSEMBLY (INCLUDES ITEMS 112 - 121)....................... 1
112 00532G4 HEX NUT, 1/4" -20.................................................................................... 2
113 629486 HEX NUT, 5/16" - 24................................................................................. 1
114 28082G01 EQUALIZER BRACKET ........................................................................... 1
115 15121G1 FLAT WASHER, 5/16" .............................................................................. 2
116 17979G1 ACCELERATOR ROD BUSHING, 2" LG.................................................. 1
117 23061G2 TUBE........................................................................................................ 1
118 23463G1 COMPRESSION SPRING........................................................................ 1
119 652256 BRAKE YOKE .......................................................................................... 1
120 11098G9 HEX LOCK NUT, 5/16" - 24...................................................................... 1
121 612557 COMPENSATOR ROD LINK.................................................................... 1
BRAKES
