Page D-5
689396 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
BRAKES
32 10386G3 Clevis Pin, .313" x .84" Lg ............................................................................... 1
33 10387G3 Cotter Pin, .094" x .75" .................................................................................... 1
34
35
36 654667 Compensator Assembly (Includes Items 37 - 49)............................................ 1
37 00532G4 Hex Nut, 5/16" - 24.................................................................................... 2
38 629486 Spherical Hex Nut, 5/16"- 24..................................................................... 1
39 28082G01 Equalizer Bracket ...................................................................................... 1
40 15121G1 Flat Washer, 3/8"....................................................................................... 2
41 17979G1 Accelerator Rod Bushing, .464" I.D. x 1" O.D. x 2" Lg.............................. 1
42 23061G2 Tube .......................................................................................................... 1
43 23463G1 Compression Spring.................................................................................. 1
44 652256 Brake Yoke................................................................................................ 1
45 11098G9 Lock Nut, 5/16" - 24 .................................................................................. 1
46 612557 Compensator Link Rod ............................................................................. 1
47 28083G01 Brake Compensator Bumper..................................................................... 2
48 624690 Brake Cable (Driver Side) ......................................................................... 1
49 624703 Brake Cable (Passenger Side).................................................................. 1
To Next Page
