Page P-3
689396 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
SEATING
26 614221 Flat Washer, 3/8" ............................................................................................. 24
27 00559G7 Flat Washer, 1/4" ............................................................................................. 4
28 11098G5 Lock Nut (Plastic), 3/8" - 16 ............................................................................. 10
29 11027G5 Flanged Lock Nut, 3/8" - 16 ............................................................................. 4
30 14390G4 Lock Nut (Plastic), 1/4" - 20 ............................................................................. 4
31 19853G1 Square Cap Tube, 1" ....................................................................................... 2
32 01006G01 Hex Washer Head Thread Forming Screw, 3/8" - 16 x 1.25" Lg ..................... 4
33 71204G01 Hex Washer Head Screw with Patch Lock, 1/4" - 20 x 7/8" Lg........................ 8
34 634178 Seat Back Support........................................................................................... 1
35 634179 Footrest Weldment .......................................................................................... 1
36 634175 Armrest (Rear Seat) ........................................................................................ 2
37 634174 Seat Frame Support ........................................................................................ 2
38 634180 Seat Frame Weldment..................................................................................... 1
To Next Page
