Page M-3
689396 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
REAR AXLE
32 639868 Ball Bearing (TMB202) ............................................................................... 2
33 639755 Counter Shaft ............................................................................................. 1
34 640744 Ball Bearing (6006) ....................................................................... 1
35 639758 Gear, 34...................................................................................................... 1
36 639869 Knock Pipe ................................................................................................. 2
37 639760 Ball Bearing (6304)..................................................................................... 2
38 639768 Flanged Hex Head Bolt, M8 - 1.25 x 40mm Lg .......................................... 1
39 639769 Gear, 17...................................................................................................... 1
40 28689G01 Collar, 24 x 7.5mm ..................................................................................... 1
41 639771 Gear, 52...................................................................................................... 1
42 670697 Center Shaft ............................................................................................... 1
43 639774 Clutch Pin ................................................................................................... 1
44 670696 Gear, 61...................................................................................................... 1
45 639797 Spacer, 20 x 2mm ...................................................................................... 2
46 639872 Differential Case (Includes Items 34, 47, 49 and 50)........................... 1
47 639800 Differential Pair Gear..................................................................... 1
48 26808G01 Hex Head Bolt, M10 - 1.25 x 26mm Lg................................................ 6
49 28723G01 Differential Shaft............................................................................ 1
50 28697G01 Spring Pin, 4 x 40L........................................................................ 1
51 639801 Ball Bearing (6007) ....................................................................... 1
52 640739 Gear, 60 Complete (Includes Item 51)................................................. 1
53 607938 Castle Nut, M22 - 1.5 ................................................................................ 2
54 639876 Axle Shaft L Complete (Includes Item 56).................................................. 1
55 639881 Axle Shaft R Complete (Includes Item 56) ................................................. 1
56 639836 Ball Bearing (6205DD)......................................................................... 2
57 607939 Axle Case L Complete................................................................................ 1
58 607940 Axle Case R Complete ............................................................................... 1
59 26814G01 Snap Ring, 52mm....................................................................................... 2
60 639839 Flanged Hex Head Bolt, M8 - 1.25 x 60mm Lg .......................................... 9
61 639840 Flanged Hex Head Bolt, M10 - 1.25 x 25mm Lg ........................................ 10
62 639844 Shift Shaft Complete .................................................................................. 1
63 639847 Differential Assembly (Includes Items 46, 48 and 52) ............................... 1
To Next Page
