5878 • 5880 • 5882
7
Identification (cont’d)
Display Icons
11. – Polarity indicator
12.
Insulation resistance test in progress
13. t Insulation resistance is less than 50 kΩ
14. y Bar graph element
15. u Insulation resistance is greater than 2 GΩ
16. Timer is active
17. ALARM Alarm is on, or programming is in progress
18. < Alarm will trigger if measured value is less than the setpoint
19. > Alarm will trigger if measured value is greater than the setpoint
20. 00:00 Timekeeper display or
0000 Setpoints
21. G 10
9
22. M 10
6
23. k 10
3
24. Ω Ohms
25. OL Overload (insulation resistance is greater than 2 GΩ or voltage is greater than 600 V)
26. V Volts
27. AC Alternating Current
28. DC Direct Current
29.
Battery status
30. Auto power off is inactive
31. Speaker is active
32. Lead resistance is compensated
33. > 25 Circuit voltage is greater than 25 volts; insulation resistance test
(yellow button) is disabled
34. Read the instruction manual
