Instruction manual EHP 3 page 17
____________________________________________________________________________
8. Technical Data
protective system: IP 54
hose length: 2 m
length of the power supply cable: 10 m
Hydraulic oil: „Shell Tellus T 15“
Temperature range (hydraulic oil): -20°C to +40°C
Version for circular voltage Type EHP 3
Weight of the complete pump: ca. 40,9 kg
nominal power: 1,1 kW
Motor voltage: 400 V/ 50-60 Hz
Volume: 0,9 l/min
max. operation pressure: 700 bar
Reservoir capacity: 4,65 l
Control voltage: 24 V DC
Sound level: < 70 dB (A) in 1m distance
Symbols
Safety warnings
Please do not disregard these instructions in order to avoid human injuries and
environmental damages.
Operational warnings
Please do not disregard them to avoid damaging the pump unit.
Remark
This instruction manual can be ordered free of charge at our Service Center. The part # is
HE.8229.
