LYCOMING OPERATOR’S MANUAL SECTION 2
O-360 AND ASSOCIATED MODELS SPECIFICATIONS
DETAIL WEIGHTS (CONT.)
Model Lbs.
IO-360 Series (Cont.)
-A1A, -A2A, -C1F, -C1G6 ....................................................................................................324
-A1C, -A2A, -A1D ................................................................................................................325
-A1B, -A2B............................................................................................................................326
-C1D6.....................................................................................................................................328
-C1C6.....................................................................................................................................329
-A1B6D, -A3B6D, -J1A6D ...................................................................................................330
-A1B6, -A3B6........................................................................................................................333
-A1D6 ....................................................................................................................................335
-C1E6 .....................................................................................................................................337
AIO-360 Series
-A1A, -A2A ...........................................................................................................................331
-A1B, -A2B, -B1B .................................................................................................................332
HIO-360 Series
-G1A ......................................................................................................................................283
-B1A, -B1B ............................................................................................................................290
-A1A ......................................................................................................................................311
-A1B.......................................................................................................................................312
-D1A, -E1AD, -E1BD............................................................................................................321
-C1A.......................................................................................................................................322
-C1B.......................................................................................................................................323
-F1AD ....................................................................................................................................324
TIO-360 Series
-C1A6D..................................................................................................................................379
-A1A, -A1B............................................................................................................................386
-A3B6.....................................................................................................................................407
DIMENSIONS, INCHES
MODEL HEIGHT WIDTH LENGTH
O-360 Series
-A1A, -A1P, -A2A
-A1C
-A1D, -A2D
-A1F, -A2F
-A1F6
-A1G, -A2G
-A1H, -A2H
24.59
19.68
24.59
24.59
24.59
19.22
19.22
33.37
33.37
33.37
33.37
33.37
33.37
33.37
29.56
30.67
29.81
30.70
30.70
31.82
31.82
2-9
