How to Remove the Chassis assembly
STEP1:
After removing the electrical box, remove 5
screws shown in the pictures.
STEP2:
The chassis is hold by the installation plate and
two snap-fit designs. Grab the indoor unit and
pull it away from the installation plate.
STEP3:
Grab both corner of the basis chassis like
picture shown; and then pull it away from the
upper chassis with a few resistance because of
two snap-fit designs.
STEP4:
After that, the chassis is disassembled.
