CYCLINDER TEST
Make sure the piston rod has been installed correctly.
1. Insert E4 into the hole of the piston rod.
2. Place the two forks of the lever tool (E10)
under E4 on either side of the piston rod.
3. Push down on the lever to lift up the piston rod,
then release. Repeat two times.
As you do this, observe the piston rod from the side:
2
3
1
x2
A
E4
E10
Push down on
the lever ...
... to li up the
piston rod.
en release
the piston.
If the piston rod
can be lied up
easily and retracts
automatically,
move on to test B.
e piston rod does not move when
you try to li it.
Go back to steps 21–23, and make
sure all parts have been installed
correctly. Or watch the demo video.
⇨
⇦
