Thames & Kosmos Ultra Bionic Blaster - Air Wheel Position Check

CYCLINDER TEST
Make sure the air wheel (A18) is in the correct position.
1. Place the notch of B7 all the way into the groove of the cylinder.
2. Slide the notch of B7 along the groove as shown.
2
1
B
B7
A11
is is the correct
position of the air wheel.
Repeat steps 1 and 2 until
it looks like this.
en, return to page 6
and proceed with step 31.
⇨
⇦
