6 Phone sockets INPUT RIGHT / INPUT LEFT
Inputs for balanced or unbalanced line level signals.
7 XLR sockets INPUT RIGHT / INPUT LEFT
Inputs for balanced signals with line level.
8 NL4 chassis connectors SAT POWER OUT RIGHT / SAT POWER OUT LEFT
Speaker outputs.
9 Mains switch POWER
To turn the device on or off.
10 IEC chassis connector with fuse holder for power supply.
If the fuse blows you have to replace it by a new one with same specifications. Before, you must disconnect the unit
from the mains power supply.
Connections and operating elements
active subwoofer
18
