The box CL 112 - Technical Specifications

6 Technical specifications
CL 112 Sub (item no. 109893) CL 115 Sub (item no. 109892)
System Active subwoofer
Speakers 1 × 12" woofer 1 × 15" woofer
Inputs XLR sockets (balanced)
1/4" phone sockets (balanced or unbalanced)
Outputs Lockable NL4 chassis connectors (1+/1-)
Impedance for passive speakers (top) to be con‐
nected
min. 4 Ω
Crossover frequency 150 Hz 130 Hz
Output power for built-in speaker 120 W (RMS) 220 W (RMS)
Output power for passive speakers (top)
2 × 120 W (RMS) 2 × 220 W (RMS)
Sound pressure level 118 dB (max.) 122 dB (max.)
Technical specifications
CL 112 / CL 115 SUB
19
