Location of Controls (Rear)
1. CDG Indicator
2. Display
3. Repeat Indicator
4. PLAY/PAUSE Indicator
5. Program Indicator
1. Mic 1 Jack
2. Mic Holders
3. Mic 2 Jack
4. Video Out Jack
5. Right Audio Out Jack
6. Left Audio Out Jack
7. DC In Jack
8. Battery Compartment
Location of Controls (Display)
4
5
1
3
2
CDG
REPEAT
PLAY/PAUSE
PROGRAM
v
v
u
x
U
w
y
V
W
