— E4 —
Location of Controls (Top/Rear)
1. CDG Indicator
2. Display
3. Repeat Indicator
4. PLAY/PAUSE Indicator
5. Program Indicator
Location of Controls (Display)
4
5
1
3
2
CDG
REPEAT
PLAY/PAUSE
PROGRAM
1. CD compartment
2. Mic Holders
3. Cradle
4. VIDEO OUT Jack
5. AUDIO OUT Right Jack
6. AUDIO OUT Left Jack
7. LINE OUT Jack
8. DC Jack
u
v
w
x
y
U
V
W
