The Singing Machine SML283BK - Control Locations; Front View Controls; Rear View Connections

E-2
CONTROL LOCATIONS
FRONT VIEW
REAR VIEW
1. Handle
27. iPhone/iPod holder
28. VIDEO OUT Jack
29. AUX OUT Jack (R)
30. AUX OUT Jack (L)
31. AUX IN Jack
32. DC IN Jack (9V)
2. SKIP button
3
. PROGRAM button
4. REPEAT button
5. MIC Volume control
6. ECHO control
8. Auto Voice control
ON/OFF button
7. Speaker (L)
9. CDG LED
10. REPEAT LED
11. Display
12. DISCO Light
14. button
13. STANDBY LED
S
TOP button .16
PLAY/PAUSE button .17
Master Volume
control .18
BALANCE control .19
Speaker (R) .20
DISCO Light
ON/OFF button .21
CD Door.24
PLAY/PAUSE LED .22
PROGRAM LED .23
MIC 1 Jack .25
MIC 2 Jack .26
Battery Door .33
SKIP button .15
