— 6 —
Connection
Connecting to AC Power
Connecting to Line In Jack
Installing the Cradle
Insert the AC power cord into a
conveniently located AC outlet
having 120V AC, 60Hz.
Note:
Make all connections before
connecting to AC power.
Connect an external device
by using an appropriate cable
(3.5mm audio cable not included)
as shown.
Note:
See page 18 to select and use the
Line In function.
Insert the cradle as shown to
utilize as a stand for your mobile
device/tablet.
To External Unit
AUDIO OUTPUT
/ HEADPHONE JACK
LINE IN
To Next Page
