Area Meaning
Display area Shows the current interconnection of input to output channels.
Input and output channels can be renamed. Click on a function area (such as ‘PEQ’ or ‘DELAY’ ) to open
the tab. Here you can enter the corresponding parameters directly.
Control area With a mouse click you can interconnect each input with each output channel. An input channel or the
mix of several input channels can be freely assigned to each output channel. The green input channels
are assigned to the respective output channel. You can adjust the level for each combination of input
and output channel.
Operating on a PC
DSP 4x4 Mini Pro
29
