• Do not operate the unit without the plastic grate on the bottom.
• Do not touch the bottom or sides of the metal tank, or a burn may result.
• Do not heat paraffin on a stove, hotplate, or in a microwave.
• Do use this appliance on a level, secure surface.
• Do not use any additives in the paraffin except as allowed by the manufacturer.
• Do not modify this equipment without authorization from the manufacturer.
Cautions
• Meets IEC/EN 60601-1-2 electromagnetic compatibility interference safety standard. (Care must be
taken when operating this equipment around other equipment. Potential electromagnetic or other
interference could occur to this or the other equipment. Minimize this interference by not using
other equipment in conjunction with it.)
• Do not remelt used paraffin, reintroduced particles or chemicals may damage the tank.
• Never use sharp objects to remove hardened paraffin from the unit.
• Do not leave an empty unit plugged in.
• Do not pour melted paraffin from the tank.
Technical Information
• Power, Model TB9: 100–125V, 1.04–1.55A, 50/60Hz
• Power, Model TB10: 220–240V, 0.52–0.775A, 50/60Hz
• Heater: TB9: 103–194 watts, TB10: 114-186 watts
• Operating temperatures:
• Quick Melt - 131º–138º F. (55º–59º C.)
• Normal - 126º–134º F. (52º–56.7º C.)
• 14.3” L x 8.2” W x 7.5” H (36.32 cm L x 20.83 cm W x 19.1 cm H)
• Capacity: 9 lbs. (4.08 kg.)
• Melt time (approximate.): Normal - 6-8 hours,
Quick Melt - 3-4 hours
• Duty cycle: continuous operation
• Degree of protection against moisture ingress: IPX0
Environmental Ratings
Operating Transport and Storage
Temperature: 65° to 85° F (18.3° to 29.4° C) -40° to 130° F (-40° to 54.4° C)
Relative Humidity: 10% to 95% 10% to 95%
Atmospheric Pressure: 70 to 160 kPa 70 to 160 kPa
NOTE: “Hospital Grade”
grounding reliability can only be
achieved when the equipment
is connected to an equivalent
receptacle marked “Hospital
Only” or “Hospital Grade”
NOTE: Current and wattage
must be measured at
operating temperature.
No. Test/Standard Port (enclosure,
AC, DC, I/O)
Emissions Class and Group /
Immunity Test Level
1 CISPR 11, Radiated Emissions Enclosure Class A; Group 1
2 IEC 61000-4-2 Enclosure ±8kV contact, ±2kV, ±4kV, ±8kV, ±15kV air
3 IEC 61000-4-3 Radiated RF
Immunity
Enclosure 3V/m, 80-2700MHz, 80% 1kHz AM
4 IEC 61000-4-3 Proximity fields
from RF wireless equipment
Enclosure Section 8.10 of the IEC 60601-1-2 standard
5 IEC 61000-4-4 AC 2kV, 100kHz repetition rate
6 IEC 61000-4-5 AC ±1kV Line-to-Line, ±2kV Line-to-Ground
7 IEC 61000-4-6 AC 3V, 0.15-80MHz, 80% 1kHz AM, 6V in ISM Band
within 0.15-80MHz, 80% 1kHz AM
8 IEC 61000-4-8 Enclosure 30A/m, 50Hz¬
9 IEC 61000-4-11 Voltage Dips AC 0% (100% reduction), 0.5 cycle; 0% (100%
reduction), 1 cycle; 70% (30% reduction) UT, 0.5 sec
10 IEC 61000-4-11 Voltage
Interruptions
AC 0% (100% reduction), 5 sec
Featuring SAFE QUICK MELT
