Thermador MicroDrawer User Manual

English 2
Table of Contents
SPECIAL WARNING
• INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
• IMPORTANT: SAVE THIS INSTALLATION MANUAL FOR LOCAL ELECTRICAL INSPECTOR’S USE.
• READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
SPECIAL WARNING....................................................................................................................................................................... 2
CLEARANCES AND DIMENSIONS .............................................................................................................................................. 2
UNPACKING YOUR MICRODRAWER™ MICROWAVE OVEN .................................................................................................... 3
IMPORTANT NOTES TO THE INSTALLER ................................................................................................................................... 3
IMPORTANT NOTES TO THE CONSUMER .................................................................................................................................. 3
MICRODRAWER™ MICROWAVE OVEN MEASUREMENTS ................................................................................................. 4 - 5
ANTI-TIP BLOCK ........................................................................................................................................................................... 5
ELECTRICAL REQUIREMENTS ................................................................................................................................................... 6
DRAWER INSTALLATION ............................................................................................................................................................. 6
BSH HOME APPLIANCES CORPORATION SUPPORT .............................................................................................................. 6
Clearances and Dimensions
• For safety considerations do not install drawer in
any combustible cabinetry which is not in accord
with the stated clearances and dimensions in the
"MicroDrawer™ Microwave Oven Measurements"
section following. See Figure 3 (standard installation) or
Figure 4 (flush installation).
• Dimensions that are shown in Figure 3 (standard
installation) or Figure 4 (flush installation) must be used.
Given dimensions provide minimum clearance. Locate
electrical outlet in the shaded area in the upper left-hand
corner of the cutout. See Figure 6.
• Supporting surface must be solid and level. Pay special
attention to the floor of the cabinet opening on which
the MicroDrawer™ microwave oven will sit. The floor of
the opening should be constructed of plywood strong
enough to support the weight of the oven (about 100
pounds).
• Check the location where the MicroDrawer™ microwave
oven
will be installed for proper electrical supply.
• Your oven can be built into a cabinet or wall as a stand-
alone unit or under a built-in gas or electric wall oven
and the followings:
GAS
COOKTOPS
ELECTRIC
COOKTOPS
INDUCTION
COOKTOPS
SGSX365FS
SGSX305FS
SGSL365KS
SGS365FS
SGS305FS
SGS304FS
CES366FS
CES365FS
CES304FS
CET366FS
CET304FS
CEM365FS
CEM304FS
CIT365KM
CIT365KBB
CIT365KB
CIT36XKB
• Check to be sure that there is a clearance of 2 inches
or greater between the top of the MicroDrawer™
microwave oven unit and the bottom of a built-in wall
oven above it.
• The microwave interior will easily accommodate a
9" x 13" oblong dish or a bag of microwave popcorn.
