Heat Pump Manual
SERVICE and MAINTENANCE
Full Setting List – again some of the settings are not for this model of heat pump and it is
recommended that THEY ARE NOT altered without a full understanding of the heat pumps
programming or without checking with Thermex first. The settings reflect Thermex
recommended setting for the installation ordered. If at a later time another heat pump is
installed in tandem or the heat pump is added to a multiple heat pump set them some of the
setting may change.
PARAMETER MENU
MENU ITEM SETTING MENU ITEM SETTING
SYSTEM MENU
SINGLE DUAL/OPN Single HIGH TEMP STOP NO
MASTER /SLAVE MASTER
SLAVE on heat pump in
redundancy
Display Alarm + Warning Alarm Only
CYCLE CHANGEOVER NO in stand-alone
installation
YES on master heat pump
in 1+N installation
Stop on Compressor fail NO for HP80 and HP100
N/A for HP20, HP40 and
HP60
No. Compressors 1 – HP20, HP40, HP60
Keypad time lock ON
Air to Water or W2W Selected as part of unit
construction
EMAIL LOG MENU
EMAIL ALARM ON/OFF OFF MANAGE DATA LOG OFF
DATA LOG PERIOD 30 seconds
SET TIME MENU
TIME ZONE Set after install SET DAY OF MONTH Set after install
SUMMERTIME ON/OFF Set after install SET WEEKDAY Set after install
SET MONTH Set after install
DELAY HOLD MENU
ALARM ACK DELAY 30 seconds COMPRESSOR HOLD TIME 120 SECONDS
FAN RUN ON TIME 30 seconds PUMP DELAY TIME 2 seconds
Compressor ON time 30 seconds Compressor off time 30
PUMP RUN ON TIME 30 seconds COMPRSSOR START TIME 5 seconds
SET POINT MENU
PULL DOWN PER MIN 0.6 LP Hyst pressure 50
TEMPERATYRE HYSTERESIS 2 LP pressure defrost 130
LAST OF HYSTERESIS 0.5 Pump delay 2 seconds
HOT WATER HIGH TEMP
ALARM
70 SET POINT TEMP 50
Evaporator water flow alarm 0.50 l/s Evaporator water flow warning 0.75l/s
Evaporator water
3C
SENSOR MENU
CCT1 SUCT PR SIZE 0-10 BAR SECONDARY SUPPLY CAL SEE PROCEDURE
CCT1 DIS PR DISCH PR SIZE 0-40 BAR AMBIENT CAL SEE PROCEDURE
