Thermo Forma 3940 - Page 15

HONEYWELL TRULINE CONFIGURATION RECORD SHT 1 OF 4
CUSTOMER:
JOB NUMBER:
UNIT SERIAL #:
CONTROL TYPE:
PREPARED BY: DATE: / /
COMPLETED BY: DATE: / /
GROUP FUNCTION VALUE OR GROUP FUNCTION VALUE OR
PROMPT
PROMPT
SELECTION
PROMPT
PROMPT
SELECTION
TUNING1 PROP BD or CHART CHRTSPD 7 DAY
GAIN HOUR/REV
RATE MIN TIME DIV 21
RSET MIN or MINOR DIV FOUR
RESET RPM or CONTINUE NO
MAN RSET CHART NAME
CYCSEC HEADER YES
PROP BD2 or REMSW NONE
GAIN2 WAKEMIN
RATE2MIN WAKE HR
RSET2MIN or WAKE DAY
RSET2RPM
WAKE MON
CYC2SEC
TIME MINUTES (CURRENT)
TUNING2 PROP BD or HOURS (CURRENT)
GAIN DAY (CURRENT)
RATE MIN MONTH (CURRENT)
RSET MIN or YEAR (CURRENT)
RSET PRM or
DAY
(CURRENT)
MAN RSET
CYCSEC PEN1 PEN1 ENABLE
PROP BD2 or PEN1IN INPUT 1
GAIN2 CHART1HI 80
RATE2MIN CHART1LO -20
RSET2MIN or PEN1ON
RSET2RPM PEN1OFF
CYC2SEC
MAJORDIV
10
MINORDIV 10
SP RAMP1
SP RAMP
RNG1TAG
TEMP
TIME MIN
FINAL SP PEN2 PEN2 ENABLE
SP RATE PEN2IN INPUT 2
EU/HR UP CHART2HI 100
EU/HR DN CHART2LO 0
SP PROG
PEN2ON
PEN2OFF
SP RAMP2 SP RAMP MAJORDIV 10
TIME MIN MINORDIV 10
FINAL SP
RING2TAG
% RH
SP RATE
EU/HR UP PEN3 PEN3 DISABLE
EU/HR DN PEN3IN
SP PROG CHART3HI
CHART3LO
PEN3ON
PEN3OFF
MAJORDIV
MINORDIV
RING 3 TAG
HTRUCON3940.xls
