Model 3920__________________________________________________________________Installation and Start-Up
2 - 5
3920 (WATLOW 982) CONFIGURATION RECORD
CUSTOMER:
JOB NUMBER:
UNT SERIAL NUMBER:
CONTROL TYPE: Temperature
PREPARED BY: DATE
COMPLETED BY: DATE
Switch Configuration:
Main Boards Input 1 Board Output 3 Option board
SW1 ON SW1 OFF Jumper switch settin
:
SW2 ON SW2 OFF Form B
SW3 ON
Software Configuration:
Operations Menus
SYS: Ei1S NA Ent4 NA A3LO -73.3 A4Hi NA
Ei2S NA A2LO NA A3Hi 34.0 Aut OFF
Ent3 NA A2Hi NA A4LO NA
PID: Pb1 2.0 dE1 NA It2 NA dB 0.0
rE1 0.50 Ct1 5 rA2 0.25
It1 NA Pb2 1.0 dE2 NA
rA1 0.19 rE2 0.25 Ct2 30
PROG: See Programming Sheets if required.
Setup Menus
InPt: In1 RT.D CAL1 ** rL2 NA CAL2 NA
dEC1 NA rtd1 DIN rH2 NA Hunt NA
rL1 -20.0 Ftr1 2 LrnL NA
rHi 80.0 In2 NA LrnH NA
OtPt: Ot1 Ht AL2 NA LAt3 nLA SIL4 NA
PrC1 NA LAt2 NA SIL3 OFF Aout NA
H
S1 0.1 SIL2 NA Ot4 NA PrC3 NA
Ot2 CL Ot3 AL3 AL4 NA ArL NA
PrC2 NA AL3 Pr1 H
S4 NA ArH NA
H
S2 0.1 H
S3 0.1 LAt4 NA ACAL NA
LbL: C_F C Anun OFF Pt
P ti PStr StPt
Err nLA LoP -100
Sd 0 LOC 2 *
Ei1 NO HiP 100 POut Cont
Ei2 NA AtSP 90 IdSP NA
* LOC should be set at 0 until factory testing and calibration is complete.
** This is a calibration factor and will vary from unit to unit.
COM: bAUd 9600 dAtA 70 PrOt FULL Addr 0
IntF NA
3920CONFIGS.XLS
PAGE1 REV3 03/30/99
