Demounting instruction C500
Page 2 of 3
Removing the C-500:
Thetford C500 completely in-
stalled (side wash room left).
To be able to remove the toilet
without problems, please follow
the steps prescribed below.
First step is to unscrew the lower
connections at the cloakroom wall
because you have to pull out the
wall later on .
Next step is to unscrew the 4 screws of
the tunnel but please don’t remove the
tunnel! This is necessary to be able to
take the cassette out of the washroom
later in process.
Then take out the cover at the bottom
and unscrew the screws below. The
12V cable must be disconnected from
the toilet next.
