Protocol ASCII- Thies-Format and MODBUS RTU
Parameter
All a/m parameters, including derivative parameters,
are depending on the respective model.
7
Electrical outputs
0 ... 10V
Electrically isolated from supply.
Attention:
For the actual scaling of the analogue outputs, please refer to the supplementary sheet "Factory
setting" on delivery or Table 9.
Quantity max. 8
Burden
Permissible burden on voltage output: ≥2000Ω.
Output
Instantaneous values, sliding means from 100msec to
2min in increments of 100msec freely selectable.
Output rate Update rate 10msec.
Resolution 16bit
Parameter
@ 4.9200.x0.xxx :
WV, WD, Temp., Rel. H., Air Pressure; Brightness,
Direction of brightness, Precipitation
@ 4.9201.x0.x0x :
WV, WD, Temp., Rel. H., Air Pressure
@ 4.9202.x0.xxx :
WV, WD, Brightness, Precipitation
@ 4.9203.x0.xxx :
WV, WD,
General
Internal measuring
rate
Wind: up to 500 propagation time measurements per
second, up to 125 complete measuring
sequences/second incl. calculations.
Temperature, humidity, pressure, precipitation,
brightness:
updated 1x a second.
Bus mode Bus mode with up to 99 devices possible.
Firmware update
Firmware update via RS422/485 with 4800
Bd..115200 Bd 8N1 in full duplex and half duplex
mode.
