User Manual of TI120 Series Variable Frequency Drive
■ Installation
Installation must be carried out by qualified personnel, otherwise there is a risk of electric
shock!
The variable frequency drive shall be installed on metal or other flame retardant objects,
otherwise there is fire danger!
The installation of the variable frequency drive shall be far away from flammable objects
and heat sources, otherwise there is fire danger!
The variable frequency drive can not be installed in an environment containing explosive
gas, otherwise there is a risk of explosion!
Do not twist the fixing bolts of equipment components at will, especially the bolts marked
with red, otherwise there is a risk of equipment damage!
It shall be handled gently, and the bottom plate of the product is held to prevent foot injury
or variable frequency drive damage!
Please install it in a place that can bear the weight of the variable frequency drive,
otherwise there is risk of equipment damage and personal injury when falling!
Please confirm that the installation environment meets the requirements of section 2.2.1. If
it cannot meet the requirements, it shall be derated or cannot be used; otherwise, it may cause
equipment failure or damage!
Avoid dropping drilling residues, thread ends and screws into the variable frequency drive
during installation; otherwise it may cause failure of variable frequency drive.
When the variable frequency drive is installed in the cabinet, heat dissipation shall be
properly handled; otherwise it may cause product failure or damage!
■
Wiring
Wiring must be carried out by qualified personnel; otherwise there is a risk of electric
shock or equipment damage!
Strictly follow this manual during wiring; otherwise there is a risk of electric shock or
equipment damage!
Only when the input power supply is completely disconnected can wiring be carried out,
otherwise there is a risk of electric shock!
