thomann Millenium MPS-1000 Assembly Instructions

Hi-hat pad
2
/
1
1
0
3
4
5
8
6
7
9
1. Unscrew the wing nut (14) from the bracket (15) and remove the felt washers (16) and the round nuts (18) from the bracket.
2. Place the two felt washers (16), the hi-hat pad (17) and the round nuts (18) on the holder one after the other, as shown in
the illustration.
3. Then tighten the wing nut (14).
4. Unscrew the wing nut (20) of the hi-hat stand (19) with pedal (21) and open up the legs. Then tighten the wing nut (20)
again.
5. Insert the hi-hat rod (22) into the Hi-Hat Stand (19) as shown in the illustration and turn the holder clockwise to secure it.
6. Adjust the height of the hi-hat rod according to your needs and then tighten the wing nut (23) of the hi-hat stand (19).
7. Attach the hi-hat pad (24) to the hi-hat rod (22) with the associated wing nut.
Assembly
e-drum set
10
