10 Mains connector with fuse holder
Connect the supplied power cord here and supply the device with mains voltage.
11 ERP ON | OFF
This switch enables/disables the standby feature. If enabled, the unit automatically
enters the standby mode when no input signal is present for at least fifteen
minutes.
12/13 Speaker outputs CH-1/2
Connect speakers to the speaker outputs of channel 1 and 2 using SPK cables
(wiring = 1+ 2+ 1– 2–).
14/15 Speaker terminals CH-1/2
You can connect the speakers either with cable lugs or bare wire to the cable termi‐
nals on the rear panel.
Connections and controls
power amplifier
18
