1 Signal (left)
2 Signal (right)
3 Ground
1 Signal
2 Ground
1/4" TRS phone plug (stereo,
unbalanced)
1/4" TS phone plug (mono,
unbalanced)
Plug and connection assignment
S-75 • S-100 • S-150
31
