thomann t.amp E-1200 - E-400 and E-800 Specs: Response, Noise, THD, Sensitivity, Gain

E-400 (item no. 173888) E-800 (item no. 173889)
4 Ω, stereo: 2 × 190 W RMS 4 Ω, stereo: 2 × 500 W RMS
Frequency response 20 Hz … 20 kHz (0 / –3 dB), ±1 dB 20 Hz … 20 kHz (0 / –3 dB), ±1 dB
Signal-to-noise ratio > 100 dB (A-weighted) > 100 dB (A-weighted)
Total harmonic distortion (THD) < 0.03 %, @ 50 % of maximum output
power
< 0,03 %, @ 50 % of maximum
output power
Sensitivity 0.77 V / 26 dB / … 1.4 V 0.77 V / 26 dB / … 1.4 V
Gain 34 dB (0.77 V), 28 dB (1.4 V) 36 dB (0.77 V), 31 dB (1.4 V)
Power consumption Typical current draw depending on the output power level (RMS value
A
RMS
). All values based on a 230 V mains voltage and a 1 kHz input signal
at 0 dB (sine).
2 × 190 W @ 4 Ω 2 × 500 W @ 4 Ω
2 × 120 W @ 8 Ω 2 × 350 W @ 8 Ω
Operating supply voltage
230 V 50 Hz 230 V 50 Hz
Fuse 5 mm × 8 mm, 8 A, 250 V, fast-acting Resettable fuse 10 A
Technical specications
power amplier
30
