4 Fuse holder.
5 OUT A | OUT B
Lockable NL4 mounting connectors for signal outputs to connect speakers.
6 OUT A | OUT B
Screw terminals (+/–) for signal outputs to connect speakers.
7 IN A | IN B
XLR mounting connectors for signal inputs.
8 IN A | IN B
1/4" phone sockets for signal inputs.
9 STEREO | PARALLEL | BRIDGED switch
Switch to select the operating modes ‘STEREO’ (both channels operate independently of each other), ‘PARALLEL’ (the
inputs of both channel are interconnected) and ‘BRIDGED’ (both channels are interconnected to form one channel
with double output power).
Connections and operating elements
power amplifier
20
