PNEUMATIC DATA
Description YP-40VC YP-70VC YP-70VC
Part number 52500402 52500073 –
Flow at rated pressure 40 l/min 70 l/min 60 l/min
Rated pressure -120 mbar -180 mbar -180 mbar
Operating range -50 to -200 mbar -50 to -200 mbar -50 to -200 mbar
ELECTRIC DATA
Motor type Linear drive Linear drive Linear drive
Voltage 230V 50Hz 230V 50Hz 115V 60Hz
Power consumption ata rated pressure 43W 84W 89W
Max current 0.53A 1.16A 2.3A
GENERAL DATA
Ambient temperature -10 to 40°C -10 to 40°C -10 to 40°C
Weight 5.3Kg 6.2Kg 6.2Kg
Inlet/Outlet diameter Rc 3/8 Rc 3/8 Rc 3/8
Average sound level 39 dB(A) 48 dB(A) 41 dB(A)
Max sound level 50 dB(A) 62 dB(A) 62 dB(A)
SERVICE PARTS
Chamber block set 700020 700038 –
Air filter and gasket kit – – –
Air filter kit – – –
Protective switch – – –
PNEUMATIC DATA
Description AP-40 AP-50G AP-60G
Part number 52500453 52500001 52500002
Flow at rated pressure 46 l/min 47 l/min 60 l/min
Rated pressure 120 mbar 200 mbar 200 mbar
Operating range 50 to 200 mbar 100 to 300 mbar 100 to 300 mbar
ELECTRIC DATA
Motor type Linear drive Linear drive Linear drive
Voltage 230V 50Hz 230V 50Hz 230V 50Hz
Power consumption ata rated pressure 0.34 A/ 29 W 0.29 A/ 31 W 0.39 A/ 41 W
Max current 0.38A 0.35A 0.45A
GENERAL DATA
Ambient temperature -10 to 40°C -10 to 40°C -10 to 40°C
Weight 4.3Kg 5.8Kg 5.8Kg
Inlet/Outlet diameter 18 mm 18 mm 18 mm
Average sound level 34 dB(A) 34 dB(A) 34 dB(A)
Max sound level 35 dB(A) 42 dB(A) 42 dB(A)
SERVICE PARTS
Chamber block set 700580 700608 700608
Air filter and gasket kit 700582Y 700582Y 700582Y
Air filter kit 7005983Y 700583Y 700583Y
Protective switch – – –
YP-VC,YP-A, LW model series specification
AP, LP model series specification
