THOMSON 32LM051B6 - Page 87

32’’ LCD TV Color Monitor Thomson 32LM051B6
87
R709 10K
MAIN-ON2
PWR_ON6,10
REMOTE 2,6
R704 100 1/16W
R705 100 1/16W
ST5V
KEY_AD2,6
U711 NT1009
1
2
3
4
5
6
7 8
9
10
11
12
13
14
LED2/GPIO8
GPIO7
GPIO6
VDD
GPIO5
GPIO4
PSW/GPIO3 HS/GPIO2
VS/GPIO1
IR/GPIO0
GND
PD/GPIO11
DAT/GPIO10
CK/GPIO9
715T1616-1
R701 100 1/16W
C701 0.01uF
C703
0.1uF
VGAHS 2,6
R707 100 1/16W
R703 100 1/16W
R702 100 1/16W
Option
SC1 2,6,
7
+
C702
10uF
SD1 2,6,
7
R708
10K
C700 0.001uF
L701 NC
R700 100 1/16W
1.0
ENERGY STAR
AOC (Top Victory) Electronics Co., Ltd.
A
12
12 Wednesday, January 04, 2006
Title
Size Document Number Rev
Date: Sheet of
R706 100 1/16W
VGAVS 2,6
