THOMSON CF20M01 - Page 45

45Automatic coffee machine CF20M01
9. Place the coffee grounds container
on the inner drip tray and return it to
its original position. (figure 1)
Note: When indicator flashes,
it means that the coffee grounds
container is missing or installed
incorrectly.
10. Set the outer drip tray to its original
position. (figure 2)
11. Unlock the panarello by turning it to
the left. Then pull down to remove it.
(figure 3)
12. Pull down the metal tip and remove it.
(figure 4)
13. Wash the panarello with warm
running water and use a hook or
cleaning brush to clean the hole.
(figure 5)
14. Rinse the metal tip with warm
running water and use a hook or
cleaning brush to clean the hole.
(figure 6)
15. Install the metal tip back on the
panarello. Then press up to set the
panarello in place. And turn right to
lock it.
(figure 1)
(figure 2)
(figure 3)
(figure 5)
(figure 6)
(figure 4)
