70 Part C

■

Framing

KEYSTROKE DISPLAY

H LEVL 68.20°

H CHK 1 36.87°

H CHK 2 53.13°

Your calculator now provides additional information—first on the irregu-

lar jack rafters, then on the regular jack rafters—using this key sequence:

Çj

IJOC T 16 INCH

j INCR 1 FEET 2-7/16 INCH

j IJ 1 7 FEET 4-5/16 INCH

j IJ 2 6 FEET 1-15/16 INCH

j IJ 3 4 FT 11-1/2 INCH

j IJ 4 3 FEET 9-1/16 INCH

j IJ 5 2 FEET 6-5/8 INCH

j IJ 6 1 FEET 4-1/4 INCH

j IJ 7 0 FEET 1-13/16 INCH

j IJ 8 0 FEET 0 INCH

j PLMB 33.69°

j LEVL 56.31°

j CHK 1 36.87°

j JKOC T 16 INCH

j INCR 1 FEET 11-7/8 INCH

j JK 1 8 FEET 7-5/8 INCH

j JK 2 6 FEET 7-3/4 INCH

j JK 3 4 FEET 7-7/8 INCH

j JK 4 2 FEET 8-1/16 INCH

j JK 5 0 FEET 8-3/16 INCH

j JK 6 0 FEET 0 INCH

j PLMB 26.57°

j LEVL 63.43°

j CHK 1 53.13°

Notice that the jack rafters for this problem are arranged in descend-

ing order. Your Construction Master Pro User’s Guide demonstrates the

keystroke sequences required to (a) arrange the rafters in ascending order

with the jacks mating at the hip/valley rafter, and (b) change the rafter spac-

ing to something other than 16⬙ o.c.
