THOMSON Construction Master Pro - Rake-wall Studs

Sample
Rafters
■
Chapter 6 71
The final structural elements to be analyzed are rake-wall studs as
shown in Figure 6-9. These may be used to support the end walls of a gable
roof, or the side walls of a shed roof. These members are essentially just
vertical jacks, and may be installed with no base, or atop a stud wall as
shown in the figure. Pitch of the roof rafters may be specified in the usual
number of ways: rise and run; rise and pitch; run and pitch; or diagonal and
pitch.
Notes
Copyright © 2007 by Calculated Industries, Inc.
and Thomson Delmar Learning
Construction Master® Pro Workbook and Study Guide
Rake Wall w/No Base
Rake Wall w/Base
(a)
(b)
Figure 6-9
