Quick
Connect Guide
This guide will help you to set up your system
through several illustrations.
Thomson multimedia
46/47 quai A. Le Gallo
92648 Boulogne Cedex
FRANCE
RCS nanterre
B 322 019 464
TOCOM 55216410
DPL900VD
Speaker Hook-Up Placement
For optimized
performance, please
follow the
recommendations and
illustration.
Left Rear Speaker (Surround)
Right Rear Speaker (Surround)
Left Front Speaker
Center
Right Front Speaker
1 Center Speaker:
Positioned on top or below the TV
set.
2 Front Speaker:
Positioned on both sides of the TV
with equal distances away from the
TV.
3 Rear Speaker:
Positioned beside or slightly behind
your favorite viewing position. The
height should be a little above your
ear level.
Subwoofer:
Positioned anywhere
NOTE:
For effective SURROUND effect, rear
speakers need to be located beside
or behind your listening position.
Advanced Set Up:
For more details on speaker
placement, please refer to the
manual chapter “Positioning
Your Speaker” (Pg. 7)
EN
3
3
2
2
1
