residual operating current not exceeding 30
mA.
- The appliance must not be connected to
the
earth wire (yellow and green wire).
ELECTRICAL CONNECTION
Blue or light gray wire connect to Neutral
(230V)
Brown or red wire connect to Phase (230V)
Black wire connect to pilot wire. Optional
function to use in case of control by pilot wire
box (do not connect to ground).
- In the absence of pilot wire, insulate the
bare end of the black wire to prevent
electrical contact with the other wires or
ground.
4.USING THE HEATER
In Comfort mode: The default temperature is 19 ℃
In Eco mode: The default temperature is 15.5 ℃
Standby mode (the device does not work but is energized)
Frost protection mode (the device maintains the room temperature at approximately
7 °C)
GB-8
