PARTS LIST NPM1525 pump 2011 series
Item Part Number Description
Q.ty
by
Pump
NPM1525R/L
1
0202.9
5
Crankcase 1
*2
0001.0
3
Plunger oil seal 3
*3
0601.0
7
"O" Ring Ø1.78x31.47 3
*4
1201.3
8
Pressure ring 18mm 3
*5
0002.51
Low pressure "U" seal, dia.18mm
3
*6
0300.16
Intermed. ring 18mm
3
*7
0002.64
High pressure "U" seal, dia.18mm
3
*8
0603.07
Copper washer G1/2
1
*9
1601.2
0
Brass plug G1/2 1
*10
1602.3
4
Manifold housing 1
*11
0601.1
9
"O" Ring Ø2.62x17.13 6
*12
3604.7
0
Valve assembly 6
*13
0601.65
"O" Ring Ø2.62x20.29 6
*14
1601.30
Valve plug
6
15
1801.0
3
Manifold stud bolt M8x65 Dacromet 8
16
1400.01
Washer Ø8,5 16
*17
0603.0
6
Copper washer G3/8 1
*18
1601.1
7
Brass plug G3/8 2
19
1503.18
Valve seat
6
20
1202.00
Valve plate
6
21
0900.30
Valve spring
6
22
0604.05
Valve cage
6
23
1802.03
Hexagonal screw M8x18
8
24
0500.61
Closed bearing housing 1
25
0601.63
"O" Ring Ø1.78x60.05 2
26
0200.06
Roller bearing 33205
2
27
0006.15
Single - ended shaft 1
28
0206.04
Crankshaft key
1
29
1600.02
Oil dip stick
1
30
0001.02
Crankshaft seal
1
31
0301.16
Shim
1
32
0500.60
Bearing housing 1
*33
0302.19
Plunger nut 3
*34
1400.12
Copper spacer Ø 11.2/15x0.5
3
*35
1200.09
Plunger 18mm
3
*36
1400.15
Copper spacer Ø 11.3/24x0.5
3
*37
0601.03
"O" Ring Ø1.78x7.66 3
*38
0009.04
Teflon ring
3
*39
0003.28
Plunger rod
3
*40
0100.01
Connecting rod
3
*41
1502.06
Connecting rod pin
3
*42
1401.02
Spring washer Ø6
6
*43
1801.05
Connecting rod screw M6x25
6
44
0601.88
"O" Ring Ø 2.62x126.67 1
45
0203.59
Crankcase cover
1
46
0601.14
"O" Ring Ø1.78x14
1
47
0700.05
Sight glass, G3/4
1
48
1801.12
Screw M6x16 4

Leuco Spa Pagina 1 03/01/2011
