Thrustmaster Ferrari F430 - Wheel Attachment and Peripheral Connection

3/12
Attaching the racing wheel to a cockpit
1. Place the racing wheel on the cockpit shelf.
2. Place two M6 screws (not included with the racing wheel) through the cockpit shelf and insert them in
the two small threaded holes located beneath the racing wheel.
Connect the pedal set and the power adapter to the racing wheel
1. Connect the pedal set to the racing wheel using the relevant connector (10) located at the back of the
racing wheel.
2. Connect the power adapter (8) using the relevant connector located at the back of the racing wheel.
3. Connect the power adapter to a standard power outlet.
ATTACHMENT / REMOVAL
DIRECTION
To tighten:
Screw counter-clockwise
To release:
Unscrew clockwise
