ATTACHING THE RACING WHEEL
Attaching the racing wheel to a table or a desktop
Start by connecting on the underside of the wheel:
- the power adapter (20);
- the quick release USB-C cable (17a) to the USB-C connector (21);
- the T2PM pedal set (23).
Make sure to follow the paths for the different cables, and attach the cables using the hook-and-loop
fastener cable holder (19).
1. Place the racing wheel on a table or any other horizontal, flat and stable surface.
2. Insert the fastening screw (14) in the attachment system (13), then tighten the device by turning the
screw counterclockwise, so that it feeds into the large threaded hole (18) located beneath the
racing wheel, until the wheel is perfectly stable.
WARNING: Never tighten the screw alone without the attachment system in place!
This could damage the racing wheel.
