Thrustmaster T300 RS User Manual

INSTALLING THE RACING WHEEL ON ITS BASE
Align the connector positions using the arrows:
Base (1) connector: Arrow pointing upwards
Racing wheel (2) connector: Arrow pointing upwards
Once the connectors are correctly positioned, simply rotate the Thrustmaster Quick Release (12) device’s
ring counterclockwise, while holding the racing wheel (2) in position.
Then, tighten the ring as much as you can: to do so, hold the ring in position and rotate the racing wheel
clockwise.
Once you have installed the racing wheel, rotate it 180° (when facing the wheel, the PlayStation® logo
should be upside down) to access the small attachment screw located on the ring of the Thrustmaster
Quick Release (12) device. Use a large Phillips screwdriver to tighten the small attachment screw (do not
use excessive force), turning it clockwise.
Do not use excessive force when tightening the small attachment screw
(using a Phillips screwdriver)!
Stop turning the screw as soon as you feel some resistance.
7/16

Thrustmaster T300 RS Specifications

General

Type	Racing Wheel
Force Feedback	Yes
Detachable Wheel	Yes
Connectivity	USB
Paddle Shifters	Yes
Compatibility	PlayStation 4, PlayStation 3, PC
Rotation Angle	270° to 1080°
Pedals	2 pedals
Wheel Diameter	28 cm
Motor	Brushless
Mounting	Clamp system
Power Supply	External
Buttons	13 action buttons (including 2 on the base) + 1 D-Pad
