Thule Kit 1312 - Roof Rack Dimensions and Fitment; X;Y Bar Spacing for 480 R;754 and 750 Feet; X;Y Bar Spacing for 480 R;754 and 480 Feet

4 503-1312-02
X
1
1
1
1
2
2
2
2
Y
X
HONDA Fit, 5-dr Hatchback, 02-04, 05-07 / *07-08 30,5
HONDA Jazz, 5-dr Hatchback, 02-04, 05-08 30,5
Y
HONDA Fit, 5-dr Hatchback, 02-04, 05-07 / *07-08 26,5
HONDA Jazz, 5-dr Hatchback, 02-04, 05-08 26,5
X inch X mm
HONDA Fit, 5-dr Hatchback, 02-04, 05-07 / *07-08 37
5
/
8
” 956 mm
HONDA Jazz, 5-dr Hatchback, 02-04, 05-08 37
5
/
8
” 956 mm
Y inch Y mm
HONDA Fit, 5-dr Hatchback, 02-04, 05-07 / *07-08 36
1
/
8
” 916 mm
HONDA Jazz, 5-dr Hatchback, 02-04, 05-08 36
1
/
8
” 916 mm
X inch/mm
Y inch/mm
3
X / Y
480R
754 750
480
