Thule Kit 1323 - Roof Rack Installation - Step 3; Bar Positioning and Dimensional Setup

503-1323 5
X
1
1
1
1
2
2
2
2
Y
X
VOLKSWAGEN Golf V, 3-dr Hatchback, 04-07 40
VOLKSWAGEN Golf V, 5-dr Hatchback, 04-07 40
VOLKSWAGEN Golf VI, 3-dr Hatchback, 08– 40
VOLKSWAGEN Golf VI, 5-dr Hatchback, 08– 40
Y
VOLKSWAGEN Golf V, 3-dr Hatchback, 04-07 29
VOLKSWAGEN Golf V, 5-dr Hatchback, 04-07 29
VOLKSWAGEN Golf VI, 3-dr Hatchback, 08– 29
VOLKSWAGEN Golf VI, 5-dr Hatchback, 08– 29
X inch X mm
VOLKSWAGEN Golf V, 3-dr Hatchback, 04-07 41
3
/
8
” 1051 mm
VOLKSWAGEN Golf V, 5-dr Hatchback, 04-07 41
3
/
8
” 1051 mm
VOLKSWAGEN Golf VI, 3-dr Hatchback, 08– 41
3
/
8
” 1051 mm
VOLKSWAGEN Golf VI, 5-dr Hatchback, 08– 41
3
/
8
” 1051 mm
Y inch Y mm
VOLKSWAGEN Golf V, 3-dr Hatchback, 04-07 37 ” 941 mm
VOLKSWAGEN Golf V, 5-dr Hatchback, 04-07 37 ” 941 mm
VOLKSWAGEN Golf VI, 3-dr Hatchback, 08– 37 ” 941 mm
VOLKSWAGEN Golf VI, 5-dr Hatchback, 08– 37 ” 941 mm
X inch/mm
Y inch/mm
3
X / Y
480R
754 750
480
