CHARGING YOUR BATTERY IN THE THUNDER WEEKENDER
The Thunder Weekender battery charger is protected from;
• Over charging
• Reverse polarity
• Over temperature
• Short circuiting
• When the Thunder Weekender 240 Volt battery charger has been connected
to the battery in reversed polarity (when using alligator clamps), the
FAULTY BATTERY LED indicator will be flashing and the charger will not
supply an output charge voltage.
• Never leave the battery charger unsupervised until the charging cycles
are complete.
Disconnecting the Thunder Weekender battery charger
• Your battery is fully charged when stage 7 is illuminated, but
can be stopped at any stage by turning off, and disconnecting at
the mains connection.
CHARGING VOLTAGES
GEL LEAD ACID / AGM CALCIUM
CHARGING STAGES 14.3 Volt 14.8 Volt 15.6 Volt
BOOST 14.8 Volt 15.2 Volt 16.2 Volt
FLOAT 13.3 Volt 13.7 Volt 13.7 Volt
EXPECTED CHARGE TIMES
YOUR BATTERY AMP HOUR RATING CHARGE TIME TO 50% CAPACITY
60Ah 5 hours
100Ah 9 hours
160Ah 14 hours
BATTERY CHARGER SPECIFICATIONS
INPUT RATING 240 VAC / 50 Hz
Operating temperature -15°C to +40°C
Maximum charge current 6 Amp
Minimum start voltage 0 Volts (will revive a completely discharged battery)
Charger type 7 stage pulse
Environment protection rating
IP65 (dust protection, and low pressure moisture protection)
