ThyssenKrupp Flow2 User Manual

2007.03.07Flow2 stairliftTab 06: Systematic fault finding
www.ThyssenKruppAccessibility.nl22
Error messages
Priority High
Possible
solution
- Switch the lift off and on.
- Check the connections on the sensor board and on the main board.
- Check in mode 3 whether the swivel function can be nulled with the middle
[E] button on the service board.
If this is not possible, replace the opto cable and if necessary also the
cable between the levelling board and the main board.
- If the above solutions do not rectify the fault, the main board can be
replaced.
- If this last solution does not rectify the fault, the swivel assembly can be
replaced.
Reset Switch off and on.
Modes 0, 1, 2
Error code E30
Type of error System error
Error message Swivel-zero opto circuit error
Description This error code indicates that the optocoupler of the swivel null point outputs
wrong signals.
Priority High
Possible
solution
- Switch the lift off and on.
- Check the connections on the sensor board level board and on the main
board.
- Replace the null opto + cable.
- Replace the cable between the levelling board and the main board.
- Replace the main board if none of the above solutions has helped or if the
fault keeps coming back. This is an extreme measure.
Reset Switch off and on.
Modes 0, 2
