ThyssenKrupp gulliver Installation Manual

01/09/2014 Orion Optional Installation Manual
9
A Terminal board
B JP8 Jumper (not to be removed or moved)
C Internal power connector
D Connectors for optional relay board
E Serial socket for connection to lift CPU
F Reset button
G RJ11 connector for local telephone
H RJ45 connector for module GSM200
I Battery
L Landline telephone board (optional)
M
Jumpers to be used in place of landline telephone board in
the case of connection to GSM module
N
Terminal boards for landline telephone connection or
universal GSM interface
O Connector for FlashKey and VoiceKey
P Device status and GSM field intensity indicator LED
Q Alarm end button (reset button)
