TIDELAND SeaBeacon 2 - Table of Contents

INSTALLATION AND OPERATION MANUAL
SeaBeacon® 2 System 6 Racon EX
0111296-00
Table of Contents
1. INSTALLATION .......................................................................................................................... 1
1.1 INSTALLATION MATERIALS SUPPLIED .............................................................................. 1
1.2 RACON MOUNTING .......................................................................................................... 2
1.2.1 Level Mounting Surfaces ........................................................................................... 3
1.2.2 Non-Level Mounting Surfaces ................................................................................... 3
1.3 CONTROL BOX MOUNTING .............................................................................................. 5
1.3.1 Initial Turn On of your Racon .................................................................................... 6
1.4 INHIBIT AND STATUS DISPLAY .......................................................................................... 6
1.4.1 Inhibiting Racon Response to Fixed Radar ............................................................... 6
1.4.2 Status Display ............................................................................................................ 7
1.4.3 Purge and Pressure, General .................................................................................... 8
1.4.4 Gather and Assemble Pure and Pressure Devices .................................................... 9
1.4.5 Purging and Pressuring ............................................................................................. 9
Table of Figures
Figure 1. Inhibit Pulse Characteristics ............................................................................................. 7
Figure 2: Functionally Equivalent Blanking Circuit Inside Room .................................................... 7
Figure 3: The GO/NO GO Circuit ..................................................................................................... 8
