11 Operators Manual
• Protective goggles (to stop dirt getting into
your eyes).
2. Transportation and Installation
Transportation and initial installation of the
machine or component are described in this
chapter.
2.1 Delivery
A machine is normally delivered in a fully
assembled state. Consult TILLSO or your
Dealer for advice on initial removal from
transportation means such as low loaders.
• A complete machine can normally be
hitched to a tractor and driven off a low-
loader.
2.2 Transportation
The machine can normally be transported on
public roads by hitching it up to a tractor or on
a low- loader.
• It is important to observe the permitted
dimensions and weights when transporting
the machine.
• If the machine or component is transported
on a trailer or a low-loader, it must be
secured using straps or other devices.
• Before transporting a machine on public
roads, it must be adjusted to its transportation
position and the stipulations relating to road
transportation fulfilled.
• The maximum permissible speed in
transport is 25km/h (16mph).
2.3 Installation
When carrying out installation
and maintenance work there is a
higher risk of injury. It is
important that you familiarise yourself with
the machine and read the Operating
Instructions beforehand.
Operator instruction and initial installation of
the machine are carried out by our service
technicians or authorised distributors.
The machine must not be used in any way
beforehand! The machine can only be
released for operation after instructions have
been provided by our service technicians or
authorised distributors.
• If any modules or parts have
been removed
for transportation, or the item is a
component rather than a fully complete
machine, these shall be mounted by our
service technicians/authorised dealers before
the instruction takes place.
• Check all important screw connections!
• Lubricate all nipples and joints!
• Check all hydraulic connections and lines
for damage.
3. Technical Data:
Rake & Roll 8m:
Working width: 8450mm
Overall width in work 8580mm
Overall length in work: 7900mm
Transport width: 2995mm
Transport height: 3800mm
Transport length: 5800mm
Total weight 5250kg
Axle load in transport: 3800kg (37278N)
Drawbar load in transport 1450kg (14225N)
Maximum drawbar uplift 1000kg (9810N)
Maximum drawbar pull provided for: 125kN
Power requirement 150/200Hp
Rake & Roll 12m:
Working width: 12250mm
Overall width in work 12380mm
Overall length in work: 9325mm
Transport width: 2995mm
Transport height: 3990mm
Transport length: 7150mm
Total weight 6800kg
Axle load in transport: 4400kg (43164N)
Drawbar load in transport 2400kg (23544N)
Maximum drawbar uplift 1250kg (12263N)
Maximum drawbar pull provided for: 125kN
Power requirement 200/275Hp
