OPERATION
Machine Overview
1. Recovery Tank
2. Vac Motor
3. 2x 12VDC Batteries
4. Solution Tank
5. Squeegee
6. Rear Caster Wheel
7. Tire
8. Scrub Deck
9. Recovery Tank Lid
10. Foam Float Ball & White Filter
11. Solution Fill Ports
12. Tank Latch
13. Charging Port
14. Recovery Drain Hose
15. Solution Sight Tube & Drain Hose
16. Squeegee Drop Lever
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
